Digital display controller

Using universal input without jumper setting, each instrument can adapt to various graduation numbers only through simple and fast parameter setting.

Description of model selection

1. For the same index number of digital display controller, the selection code is different from the instrument programming code. Please pay attention to the instrument setting.

2. Swp-c70, C10 series digital display controller has no frequency signal input.

3. C80 series is 0.8 inch LED display, C90, S80, C70, C40 series is 0.56 inch LED display, C10 series is 0.32 inch LED display.

4. Four limit control or four limit alarm outputs are four relay control outputs. The user can modify the internal parameters to set the required control or alarm mode（ Four limit control / alarm is only available for t.c80, S80 and C90 series. 2H represents two upper limit control / alarm and 2L represents two lower limit control / alarm).

Examples of common models

Swp-c401-00-nn-08 digital display controller, 48 * 48mm, PT100 input, no relay.

Swp-c801-00-nn-08 digital display controller, 160 * 80mm, PT100 input, no relay.

Swp-c403-00-hl-08 digital display controller, 48 * 48mm, PT100 input, with upper and lower limit alarm.

Swp-c803-00-hl-12 digital display controller, 160 * 80mm, 4-20mA input, with upper and lower limit alarm.

Swp-c903-00-hl-12 digital display controller, 96 * 96mm, 4-20mA input, with upper and lower limit alarm.
